BMW 7 series E38 (1994-1998) Wiring diagram engine performance 5.4l, electronic throttle control circuit

BLK WIRE BLK/YEL WIRE BLK/YEL/WHT WIRE BLU WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLK/WHT WIRE BRN/ORG WIRE CYL 1-6 ELECTRONIC THROTTLE POSITION ACTUATOR (LEFT FRONT OF ENGINE) CYL 7-12 ELECTRONIC THROTTLE POSITION ACTUATOR (RIGHT SIDE OF ENGINE) ENGINE ELECTRONICS FUSE CARRIER FUSE 4 GRN WIRE GRN/WHT WIRE GROUND GROUND POT 1 GROUND POT 2 GRY WIRE GRY/GRN WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LIGHT MODULE MOTOR 1 MOTOR 2 RED WIRE RED/WHT WIRE RED/WHT/YEL WIRE SENSOR 1 SENSOR 2 SHIELD SHIELD SHIELD SHIELD SHIELD POT 2 SHIELD POT 1 SHIELD STANDBY IND VIO WIRE VIO/WHT WIRE YEL WIRE YEL/RED WIRE YEL/RED/WHT WIRE

4 3 5 CAN BUS HI CAN BUS LOW CAN BUS SHIELD BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/VIO WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH (ABOVE BRAKE PEDAL) BRAKE SW INPUT INERTIA FUEL SW STEERING SIGNAL BRN/BLK WIRE BRN/GRY WIRE COIL SPRING CRUISE CONTROL INPUT CRUISE SW INPUT DATA LINK CONNECTOR (RIGHT SIDE OF ENGINE COMPT) ENGINE CONTROL MODULE II ENGINE CONTROLS CIRCUIT GRY WIRE KICK DOWN SW KICK DOWN SWITCH (DRIVER'S SIDE FOOTWELL) NCA WIRE PEDAL POSITION SENSOR PEDAL POSITION SENSOR (BEHIND LEFT SIDE OF DASH TOP) RED WIRE RED/WHT/YEL WIRE SHIELD SHIELD CAN BUS SHIELD CAN BUS LOW CAN BUS HI SHIELD SHIELD SHIELD SHIELD SENSOR SHIELD SENSOR SHIELD TXD VIO WIRE WHT WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
