BMW 7 series E38 (1994-1998) light reading Wiring diagram
This page shows the only wiring diagram for the component.light reading, which is found in the car BMW 7 series E38 (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light reading (1 of 1)
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
CASSETTE BOX LIGHT
FRONT CIGAR LIGHTER
FRONT INTERIOR/ READING LIGHT
GLOVE BOX LIGHT
GLOVE BOX LIGHT SWITCH
GRY/BRN WIRE
GRY/RED WIRE
INDIRECT LIGHTING
INTERIOR LIGHTS SYSTEM (INSTRUMENTAL LIGHTS CIRCUIT)
LEFT REAR ASHTRAY LIGHT
LEFT REAR INTERIOR LIGHT
LIGHT INTERIOR
LIGHT MODULE (LEFT SIDE OF DASH)
LIGHT READING
LIGHT TOP
OFF
OFF OFF ON
OFF ON
READING LIGHT
REAR CIGAR LIGHTER
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR ASHTRAY LIGHT
RIGHT REAR INTERIOR LIGHT
TRUNK COMPARTMENT LIGHT
TRUNK LID LAMP
TRUNK LID SWITCH
WHT/BRN WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> LIGHT READING
