BMW 7 series E38 (1994-1998) heated oxygen sensor ii Wiring diagram
This page shows the only wiring diagram for the component.heated oxygen sensor ii, which is found in the car BMW 7 series E38 (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heated oxygen sensor ii (1 of 1)
2 OF 6)
BLK WIRE
BRN WIRE
DATA LINK CONNECTOR
ENGINE CONTROL MODULE I (DME)
ENGINE CONTROL MODULE II (DME)
ENGINE CONTROL MODULE RELAY I
ENGINE CONTROL MODULE RELAY II
ENGINE ELECTRONICS FUSE CARRIER
FROM FUSE
FROM IGNITION SWITCH (DIAGRAM 2 OF 6)
FUEL FUEL INJECTION INJECTION
FUEL INJECTION
FUSE
GRN WIRE
HEATED HEATED OXYGEN OXYGEN SENSOR II SENSOR I
HEATED OXYGEN SENSOR I
HEATED OXYGEN SENSOR II
HOT-FILM MASS AIR FLOW SENSOR 1
HOT-FILM MASS AIR FLOW SENSOR 2
IGNITION COIL 1
IGNITION COIL 2
NCA WIRE
RED WIRE
TERMINAL 15 UNLOADER RELAY (1997 LATE PROD, 1998)
THROTTLE POSITION CONTROL MODULE (EML)
TRANSMISSION CONTROL (AGS)
W/ 1996, 1997 W/ 1998
W/ 1997 EARLY PROD, 1996 W/ 1997 LATE PROD, 1998
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 6) -> HEATED OXYGEN SENSOR II
