Anti-theft & central locking circuit, coupe for BMW 6 series F06/F13/F12 (2011-2015)

AERIAL DIVERSITY BLK WIRE BLK/BLU WIRE BLK/BLU/YEL WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/RED WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE CAR ACCESS SYSTEM (CAS) CONTROL UNIT (UNDER CENTER OF REAR SHELF) CENTRAL LOCKING BUTTON HAZARD WARNING SWITCH OPERATING FACILITY COMPUTER DATA LINES SYSTEM DRIVER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE DRIVER'S DOOR SYSTEM LOCK (REAR OF DRIVER'S DOOR) ELECTRONICS JUNCTION BOX JUNCTION BOX ELECTRONICS (UNDER RIGHT SIDE OF DASH) FOOTWELL MODULE (LEFT END OF DASH) FUSE 14 FUSE 15 FUSE 58 GRN/BLK WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE HOT AT ALL TIMES HOTEL POSITION SWITCH NCA WIRE ORG/ WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE VIO WIRE VIO/BLU WIRE VIO/GRN WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED/YEL WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE YEL/WHT WIRE

ANTI- THEFT ALARM LED BLK/BLU/YEL WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/RED WIRE BLU/GRY WIRE BLU/WHT WIRE BONNET CONTACT SWITCH BRN WIRE BRN/BLK WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR REAR AUTOMATIC SOFT-CLOSE DRIVE (GRAN COUPE) ELECTROCHROMIC INTERIOR REAR VIEW MIRROR GRN/BLK WIRE GRY/BLK/YEL WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE HIGH VARIANT ROOF FUNCTIONS MODULE INTERIOR REAR LID BUTTON NCA WIRE ORG/ WIRE REAR LID CENTRAL ARREST BUTTON RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE VIO/GRN WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/RED/YEL WIRE YEL/BRN WIRE YEL/RED WIRE YEL/WHT WIRE

BLK/BRN WIRE BLK/GRY WIRE BLU WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE DRIVER'S SIDE REAR POWER WINDOW SWITCH EXTERIOR BOOT LID BUTTON FRONT PASSENGER SIDE REAR DOOR LOCK (GRAN COUPE) FUSE 110 FUSE 144 FUSE 143 FUSE 149 DISTRIBUTION BOX) FUSE 152 FUSE 169 GRAN COUPE W/ ELECTRICALLY OPERATED ROLLER SUN BLINDS GRN WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ TERMINAL NCA WIRE ORG/ WIRE PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE PASSENGER'S DOOR SYSTEM LOCK (REAR OF FRONT PASSENGER'S DOOR) PASSENGER'S SIDE REAR AUTOMATIC SOFT-CLOSE DRIVE (GRAN COUPE) POWER DISTRIBUTION SYSTEM REAR FUSE CARRIER (IN REAR POWER RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE TRUNK LID ACTUATION W/ REVERSE CAMERA (IF EQUIPPED) (CENTER OF REAR LID) W/ REVERSE CAMERA W/O REVERSE CAMERA WHT/BLK WIRE WHT/BRN WIRE YEL/WHT WIRE
