Rear heater & a/c circuit for BMW 6 series F06/F13/F12 (2011-2015)

BLK/BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLK/YEL WIRE FUSE 177 FUSE 195 FUSE 202 GRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ JUNCTION LEFT REAR COMPARTMENT FOOTWELL TEMPERATURE SENSOR LEFT REAR COMPARTMENT STRATIFICATION ACTUATOR LEFT REAR ELECTRIC AUXILIARY HEATER LOCATOR LIGHTING NCA WIRE ORG/GRN WIRE REAR COMPARTMENT AUTOMATIC CLIMATE CONTROL REAR COMPARTMENT BLOWER MOTOR (REAR OF CENTER CONSOLE) REAR COMPARTMENT FAN MOTOR OUTPUT STAGE (ON REAR COMPT FAN MOTOR) REAR COMPARTMENT VENTILATION GRILLE REAR FUSE HOLDER (IN REAR POWER DISTRIBUTION BOX) RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RELAY ENERGIZED FUSE 31 BOX (UNDER RIGHT SIDE OF DASH) RIGHT REAR COMPARTMENT FOOTWELL TEMPERATURE SENSOR RIGHT REAR COMPARTMENT VENTILATION TEMPERATURE SENSOR RIGHT SIG STRATIFICATION LEFT SIG TEMP SENS RIGHT SIG TEMP SENS WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLU WIRE YEL/GRN WIRE
