BMW 6 series F06/F13/F12 (2011-2015) w/ automatic engine start/stop function Wiring diagram

BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE CAR ACCESS SYSTEM (CAS) CONTROL UNIT (UNDER CENTER OF REAR SHELF) CAS SUB BUS LOCK ACT LED ACT SW SIG COMPUTER DATA LINES SYSTEM DOOR LOCKS SYSTEM COMPUTER DATA LINES SYSTEM DRIVER ELECTRONIC OUTER DOOR HANDLE MODULE DRIVER'S SIDE EXTERIOR AERIAL (IN DRIVER'S DOOR) FRONT PASSENGER'S SIDE EXTERIOR AERIAL (IN FRONT PASSENGER'S DOOR) GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED/YEL WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HALL SENS GND HALL SENS SPLY GROUND AERIAL SIGNAL HALL SENS SPLY HALL SENS SIG HALL SENS SIG LED ACTIVATION AERIAL SIGNAL LOCK SPLY LOCK GND ORG/ WIRE PASSENGER ELECTRONIC OUTER DOOR HANDLE MODULE RED WIRE RED/WHT WIRE RING AERIAL START-STOP BUTTON W/ AUTOMATIC ENGINE START/STOP FUNCTION WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE
