BMW 6 series F06/F13/F12 (2011-2015) right steering wheel multi-function switch block Wiring diagram

This page shows the only wiring diagram for the component.right steering wheel multi-function switch block, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram right steering wheel multi-function switch block (1 of 1)

Wiring diagram right steering wheel multi-function switch block for BMW 6 series F06/F13/F12 (2011-2015)

Get access

1 2 M+ M- 1 4 2 3 LHZ+ LHZ- T LHZ+ T LHZ- 11 9 GND SPLY AUSW BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/VIO WIRE FUSE 24 BOX (UNDER RIGHT SIDE OF DASH) GND BWM BFI RAENDEL GRN/BLU WIRE HORN BUTTON JUNCTION JUNCTION BOX ELECTRONICS LEFT STEERING WHEEL MULTI-FUNCTION SWITCH BLOCK NCA WIRE ORG/GRN WIRE RED WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT ELECTRONIC STEERING WHEEL MODULE RIGHT STEERING WHEEL MULTI-FUNCTION SWITCH BLOCK STEERING COLUMN SWITCH CLUSTER STEERING WHEEL HEATER STEERING WHEEL HEATER, STEERING COLUMN ADJUSTMENT SWITCH VIBRATION ACTIVATOR VIO WIRE YEL WIRE

Go to component: -> Heated steering wheel circuit -> RIGHT STEERING WHEEL MULTI-FUNCTION SWITCH BLOCK
