BMW 6 series F06/F13/F12 (2011-2015) right front stratification flap motor Wiring diagrams
This page contains all the electrical diagrams for the component. right front stratification flap motor, in which he is found in the car BMW 6 series F06/F13/F12 (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front stratification flap motor (1 of 3)
A/C COMPRESSOR
AUXILIARY WATER PUMP (LEFT FRONT OF ENGINE COMPT)
BLK/GRN WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
CONTROL VALVE
DEFROSTER FLAP MOTOR (BEHIND LEFT SIDE OF DASH)
DRIVER SIDE HEAT EXCHANGER WATER VALVE
ELECTRIC FAN (FRONT OF ENGINE COMPT)
ELECTRONICS JUNCTION BOX
EVAPORATOR TEMPERATURE SENSOR (ON A/C EVAPORATOR)
FRESH AIR FLAP MOTOR
FRONT PASSENGER'S SIDE HEAT EXCHANGER WATER VALVE
GRY WIRE
HOT AT ALL TIMES JUNCTION BOX FUSE 71 (UNDER RIGHT SIDE OF DASH)
LEFT FRONT FOOTWELL FLAP MOTOR
LEFT FRONT STRATIFICATION FLAP MOTOR
LEFT FRONT VENTILATION TEMPERATURE SENSOR
LEFT HEATING EXCHANGER TEMPERATURE SENSOR
LEFT OUTER VENTILATION FLAP MOTOR
MAGNETIC CLUTCH
RECIRCULATED AIR FLAP MOTOR
RED WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT FOOTWELL FLAP MOTOR
RIGHT FRONT STRATIFICATION FLAP MOTOR
RIGHT FRONT VENTILATION TEMPERATURE SENSOR
RIGHT HEATING EXCHANGER TEMPERATURE SENSOR (BEHIND CENTER OF DASH)
RIGHT OUTER VENTILATION FLAP MOTOR
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
W/O TWIN-CLUTCH GEAR BOX
WATER VALVE ASSEMBLY (LEFT REAR OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit (2 of 3) -> RIGHT FRONT STRATIFICATION FLAP MOTOR
Wiring diagram right front stratification flap motor (2 of 3)
A/C COMPRESSOR
AUXILIARY WATER PUMP (LEFT FRONT OF ENGINE COMPT)
BLK/YEL WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
CONTROL VALVE
DEFROSTER FLAP MOTOR (BEHIND LEFT SIDE OF DASH)
DRIVER SIDE HEAT EXCHANGER WATER VALVE
ELECTRONICS JUNCTION BOX
EVAPORATOR TEMPERATURE SENSOR (ON A/C EVAPORATOR)
FRESH AIR FLAP MOTOR
FRONT PASSENGER'S HEAT EXCHANGER WATER VALVE
FUSE 71
GRY WIRE
HOT AT ALL TIMES
HOT W/
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FOOTWELL FLAP MOTOR (BEHIND LEFT SIDE OF DASH)
LEFT FRONT STRATIFICATION FLAP MOTOR
LEFT FRONT VENTILATION TEMPERATURE SENSOR
LEFT HEAT EXCHANGER TEMPERATURE SENSOR (BEHIND CENTER OF DASH)
LEFT VENTILATION FLAP MOTOR (BEHIND LEFT SIDE OF DASH)
MAGNETIC CLUTCH
REAR COMPARTMENT FLAP MOTOR
RECIRCULATED AIR FLAP MOTOR
RED WIRE
RED/BRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RELAY ENERGIZED REAR FUSE FUSE 137 CARRIER (IN REAR POWER DISTRIBUTION BOX)
RIGHT FOOTWELL FLAP MOTOR (BEHIND RIGHT SIDE OF DASH)
RIGHT FRONT STRATIFICATION FLAP MOTOR
RIGHT FRONT VENTILATION TEMPERATURE SENSOR
RIGHT HEAT EXCHANGER TEMPERATURE SENSOR (BEHIND CENTER OF DASH)
RIGHT VENTILATION FLAP MOTOR (BEHIND RIGHT SIDE OF DASH)
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WATER VALVE ASSEMBLY (LEFT REAR OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, without rear compartment blower (2 of 3) -> RIGHT FRONT STRATIFICATION FLAP MOTOR
Wiring diagram right front stratification flap motor (3 of 3)
A/C COMPRESSOR
AUXILIARY WATER PUMP (LEFT FRONT OF ENGINE COMPT)
BLK/BRN WIRE
BLK/YEL WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL VALVE
DEFROSTER FLAP MOTOR (BEHIND LEFT SIDE OF DASH)
DRIVER SIDE HEAT EXCHANGER WATER VALVE
ELECTRONICS JUNCTION BOX
FLAP MOTOR (BEHIND LEFT SIDE OF DASH)
FRESH AIR RECIRCULATED AIR FLAP MOTOR FLAP MOTOR
FRONT PASSENGER'S SIDE HEAT EXCHANGER WATER VALVE
FUSE 137
GRY/RED WIRE
HOT W/
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FOOTWELL)
LEFT FRONT STRATIFICATION FLAP MOTOR
LEFT REAR COMPARTMENT FOOTWELL FLAP MOTOR
LEFT REAR STRATIFYING AIR FLAP MOTOR
LEFT VENTILATION FLAP MOTOR (BEHIND LEFT SIDE OF DASH)
MAGNETIC CLUTCH
REAR COMPARTMENT VENTILATION GRILLE
REAR FUSE CARRIER (IN REAR POWER DISTRIBUTION BOX)
RED WIRE
RED/BRN WIRE
RED/GRY WIRE
RELAY ENERGIZED
RIGHT FOOTWELL FLAP MOTOR (BEHIND RIGHT SIDE OF DASH)
RIGHT FRONT STRATIFICATION FLAP MOTOR
RIGHT REAR COMPARTMENT FOOTWELL FLAP MOTOR
RIGHT REAR STRATIFYING AIR FLAP MOTOR
RIGHT VENTILATION FLAP MOTOR (BEHIND RIGHT SIDE OF DASH)
VIO WIRE
VIO/BLK WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
VIO/WHT WIRE
WATER VALVE ASSEMBLY (LEFT REAR OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, with rear compartment blower (2 of 3) -> RIGHT FRONT STRATIFICATION FLAP MOTOR
