BMW 6 series F06/F13/F12 (2011-2015) right exterior passenger mirror electronic outer door handle module Wiring diagram
This page shows the only wiring diagram for the component.right exterior passenger mirror electronic outer door handle module, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right exterior passenger mirror electronic outer door handle module (1 of 1)
4.4L TWIN TURBO
BRN WIRE
BRN/WHT WIRE
CONNECTION
CONNECTION 1
CONNECTION 3
CONNECTION 4
ELECTRONIC DAMPER CONTROL
ELECTRONICS JUNCTION BOX
FRONT CENTER GEAR ARMREST SELECTOR LIGHT SWITCH
FRONT CIGARETTE
GEAR SELECTOR SWITCH
GRAN COUPE
IGNITION COIL 4
IGNITION COIL 5
IGNITION IGNITION COIL 3 COIL 2
IGNITION IGNITION IGNITION COIL 8 COIL 6 COIL 7
JUNCTION BOX
LIGHT RIGHT REAR REPEATER SPEAKER LIGHTING
NCA WIRE
PASSENGER'S DOOR ENTRANCE LIGHT
PASSENGER'S DOOR TRIM PANEL LIGHTING
PASSENGER'S SEAT MODULE
RIGHT EXTERIOR PASSENGER MIRROR ELECTRONIC OUTER DOOR HANDLE MODULE
RIGHT FRONT LIGHTING PASSENGER'S MID-RANGE DOOR POCKET SPEAKER LIGHTING
RIGHT FRONT LIGHTING TWEETER
RIGHT REAR SIDE TRIM PANEL LIGHTING RIGHT FRONT ENTRANCE LIGHT
RIGHT REVERSIBLE ELECTRICALLY MOTORIZED REEL
W/ INTERIOR LIGHT PACKAGE
W/ LUMBAR SUPPORT
W/O LUMBAR SUPPORT W/O INTERIOR LIGHT PACKAGE
WINDSHIELD RIGHT FRONT WASHER DIRECTION INDICATOR PUMP
Go to component: -> Ground distribution circuit (2 of 6) -> RIGHT EXTERIOR PASSENGER MIRROR ELECTRONIC OUTER DOOR HANDLE MODULE
