BMW 6 series F06/F13/F12 (2011-2015) pt-can pt-can pt-can pt-can Wiring diagram

This page shows the only wiring diagram for the component.pt-can pt-can pt-can pt-can, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram pt-can pt-can pt-can pt-can (1 of 1)

Wiring diagram pt-can pt-can pt-can pt-can for BMW 6 series F06/F13/F12 (2011-2015)

Get access

1 2 3 4 5 6 7 PWR SPLY WAKEUP SIG PT-CAN PT-CAN GND PT-CAN PT-CAN 3.0L TURBO 4.4L TWIN TURBO BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRONICS JUNCTION FUSE 64 BOX (JBE) (UNDER RIGHT SIDE OF DASH) FUSE 63 GEAR SELECTOR SWITCH GRN WIRE GRN/RED WIRE HOT W/ TERMINAL LEFT SHIFT PADDLE NCA WIRE PT-CAN PT-CAN PT-CAN PT-CAN PWR SPLY GND RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT SHIFT PADDLE STEERING COLUMN SWITCH CLUSTER WAKEUP SIG WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE

Go to component: -> A/t circuit -> PT-CAN PT-CAN PT-CAN PT-CAN
