BMW 6 series F06/F13/F12 (2011-2015) hall sensor actuator motor Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 DEPTH TILT HEIGHT 1 2 3 4 SEAT BACKREST SIG TEMP SENS SEAT BACKREST 1 2 3 4 SEAT CUSHION 43 44 CAN 2 L CAN 2 H ACTUATOR MOTOR BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/ORG WIRE BRN/RED WIRE BUS SIG BUS SIG BUS SIG PWR SPLY GND COMPUTER DATA LINES SYSTEM FOOTWELL MODULE (LEFT END OF DASH) FOR/BACK FUSE FUSE (UNDER RIGHT SIDE OF DASH) GRN WIRE GRN/BRN WIRE GRY/WHT WIRE GRY/YEL WIRE HALL SENSOR HALL SENSOR ACTUATOR MOTOR JUNCTION BOX NCA WIRE ORG/GRN WIRE PASSENGER'S SEAT DEPTH ADJUSTMENT DRIVE (W/ MULTI-FUNCTION SEAT) POWER DISTRIBUTION SYSTEM RED WIRE RED/BLU WIRE RED/BRN WIRE RED/WHT WIRE RELAY ENERGIZED SEATS SYSTEM SIG TEMP SENS SEAT CUSHION VIO/BRN WIRE W/O LUMBER SUPPORT W/ LUMBER SUPPORT WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/BRN WIRE YEL/RED WIRE
