BMW 6 series F06/F13/F12 (2011-2015) front passenger active seat pressure distributor 2 Wiring diagram
This page shows the only wiring diagram for the component.front passenger active seat pressure distributor 2, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger active seat pressure distributor 2 (1 of 1)
3 4 5 GND PWR SPLY BUS SIG
4 5 6 7 8 BUS SIG BUS SIG BUS SIG PWR SPLY GND
BLK/BLU WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER ACTIVE SEAT PRESSURE DISTRIBUTOR
DRIVER ACTIVE SEAT PRESSURE DISTRIBUTOR 2
DRIVER'S LUMBAR SUPPORT VALVE BLOCK (TOP OF DRIVER'S SEAT BACK)
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER
FRONT PASSENGER ACTIVE SEAT PRESSURE DISTRIBUTOR 2
FUSE
FUSE FUSE
GRN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
ORG/GRN WIRE
PASSENGER ACTIVE SEAT PRESSURE DISTRIBUTOR
PASSENGER'S LUMBAR SUPPORT VALVE BLOCK (TOP OF FRONT PASSENGER'S SEAT BACK)
PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RELAY ENERGIZED
VALVE 1
VALVE 2
VALVE 3
VALVE 4
WHT/BLU WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Front lumbar circuit, with active seats -> FRONT PASSENGER ACTIVE SEAT PRESSURE DISTRIBUTOR 2
