BMW 6 series F06/F13/F12 (2011-2015) electromotive throttle valve actuator 2 Wiring diagram

This page shows the only wiring diagram for the component.electromotive throttle valve actuator 2, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram electromotive throttle valve actuator 2 (1 of 1)

Wiring diagram electromotive throttle valve actuator 2 for BMW 6 series F06/F13/F12 (2011-2015)

Get access

BLK/BLU WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CHARGING PRESSURE SENSOR 2 DIGITAL MOTOR ELECTRONICS (TOP RIGHT REAR OF ENGINE) DIGITAL MOTOR ELECTRONICS 2 (TOP LEFT REAR ELECTROMOTIVE THROTTLE VALVE ACTUATOR 2 INTAKE AIR TEMPERATURE/ MANIFOLD PRESSURE SENSOR 2 MOTOR POSITION SENSOR MOTOR POSITION SENSOR VALVETRONIC ACTUATOR MOTOR (RIGHT SIDE OF ENGINE) OF ENGINE) RAIL PRESSURE SENSOR 2 RED WIRE RED/GRN WIRE VALVETRONIC SERVOMOTOR 2 WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component: -> Wiring diagram engine performance 4.4l twin turbo (7 of 11) -> ELECTROMOTIVE THROTTLE VALVE ACTUATOR 2
