BMW 6 series F06/F13/F12 (2011-2015) elect fan activation Wiring diagrams
This page contains all the electrical diagrams for the component. elect fan activation, in which he is found in the car BMW 6 series F06/F13/F12 (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
elect fan activation wiring diagram (1 of 2)
12 18 LIN BUS SIG FAN ACTIVATION
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
CHARACTERISTIC MAP THERMOSTAT (FRONT OF ENGINE)
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS (TOP RIGHT REAR OF ENGINE)
ELECT FAN ACTIVATION
ELECTRIC FAN (FRONT OF ENGINE COMPT)
ELECTRIC FAN CUTOFF RELAY (RIGHT FRONT OF BATTERY COMPT)
ENERGIZED JUNCTION FUSE 46 BOX (UNDER RIGHT SIDE OF DASH)
ENGINE COOLANT TEMPERATURE SENSOR (ON COOLANT PUMP HOUSING)
FRONT POWER DISTRIBUTION BOX (UNDER RIGHT SIDE OF DASH)
FUSE 505
FUSE 59
FUSE BOX (INSTALLED ON BATTERY)
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
INTERCOOLER COOLANT PUMP
NCA WIRE
POWER DISTRIBUTION SYSTEM
RADIATOR OUTLET TEMPERATURE SENSOR (FRONT OF ENGINE COMPT)
RADIATOR SHUTTER SOLENOID
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
SOLENOID ACTIVATION
TURBOCHARGER COOLANT PUMP
VIO WIRE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component -> Automatic a/c circuit, without rear compartment blower (3 of 3) -> ELECT FAN ACTIVATION
