BMW 6 series F06/F13/F12 (2011-2015) driver's rear side power window switch Wiring diagram
This page shows the only wiring diagram for the component.driver's rear side power window switch, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's rear side power window switch (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER POWER WINDOW DRIVE
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S REAR SIDE POWER WINDOW DRIVE (GRAN COUPE)
DRIVER'S REAR SIDE POWER WINDOW SWITCH
ELECTRONICS JUNCTION BOX
FOOTWELL MODULE (LEFT END OF DASH)
FUSE 16
FUSE 66
GRAN COUPE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT W/ BISTABLE RELAY ENERGIZED
HOT W/ TERMINAL
JUNCTION BOX ELECTRONICS (JBE) (UNDER RIGHT SIDE OF DASH)
PASSENGER POWER WINDOW DRIVE
PASSENGER'S DOOR POWER WINDOW SWITCH
PASSENGER'S REAR SIDE POWER WINDOW DRIVE (GRAN COUPE)
PASSENGER'S REAR SIDE POWER WINDOW SWITCH
POWER DISTRIBUTION SYSTEM
RED/GRY WIRE
RED/WHT WIRE
W/ ELECTRICALLY OPERATED ROLLER SUN BLINDS
W/O ELECTRICALLY OPERATED ROLLER SUN BLINDS
WHT/BRN WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Power windows circuit -> DRIVER'S REAR SIDE POWER WINDOW SWITCH
