BMW 6 series F06/F13/F12 (2011-2015) charging pressure sensor Wiring diagram
This page shows the only wiring diagram for the component.charging pressure sensor, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram charging pressure sensor (1 of 1)
BLK/BLU WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CHARGING PRESSURE SENSOR
DIGITAL MOTOR ELECTRONICS (TOP RIGHT REAR OF ENGINE)
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 4.4l twin turbo (5 of 11) -> CHARGING PRESSURE SENSOR
