BMW 6 series F06/F13/F12 (2011-2015) capacitor box Wiring diagram
This page shows the only wiring diagram for the component.capacitor box, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram capacitor box (1 of 1)
4.4L TWIN TURBO 3.0L TURBO LATE PRODUCTION EARLY PRODUCTION
A/C COMPRESSOR
ACTIVE CRUISE CONTROL
BLK WIRE
BRN WIRE
CAPACITOR BOX
CENTER WASHER NOZZLE HEATER
CHARGE AIR COOLER COOLANT PUMP
CHARGE AIR COOLER COOLANT PUMP 2
FUEL WATER FILTER VALVES HEATING
HIGH LOW RANGE RANGE HORN HORN
INDEPENDENT AUXILIARY HEATER
LEFT FOG LIGHT
LEFT FRONT BREAK PAD WEAR SENSOR
LEFT FRONT DAMPER SATELLITE
LEFT FRONT DIRECTION INDICATOR LIGHT REPEATER
LEFT HEADLIGHT
LEFT INNER TAIL- LIGHT
LEFT WASHER NOZZLE HEATER
NCA WIRE
OIL LEVEL SWITCH
POWER DISTRIBUTION
RADIATOR BONNET SHUTTER CONTACT DRIVE UNIT SWITCH
RIGHT FOG LIGHT
RIGHT FRONT DAMPER SATELLITE
RIGHT HEADLIGHT
RIGHT INNER TAIL LIGHT
RIGHT WASHER NOZZLE HEATER
TRUNK LID ACTUATION W/REVERSING CAMERA (IF EQUIPPED)
WIPER MODULE
Go to component: -> Ground distribution circuit (5 of 6) -> CAPACITOR BOX
