BMW 6 series F06/F13/F12 (2011-2015) auxiliary brake light Wiring diagram
This page shows the only wiring diagram for the component.auxiliary brake light, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auxiliary brake light (1 of 1)
AUXILIARY BRAKE LIGHT
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRAKE DYNAMIC
BRAKE LIGHT
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
CORNERING
CORNERING LIGHT MODULE (W/ LED)
DIRECTION IND
DIRECTION IND (W/ LED)
EXCEPT GRAN COUPE
GRAN COUPE
GRN/BLU WIRE
GRN/GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEADLIGHT DRIVER MODULE
LEFT "C" PILLAR)
LEFT INNER TAILLIGHT
LIGHT
LIGHT MODULE
LIGHT TAIL
PARKING LIGHTS/ DRL LIGHT
RED WIRE
RED/BLU WIRE
RIGHT FRONT DIRECTION INDICATOR REPEATER LIGHT
RIGHT HEADLIGHT
RIGHT INNER TAILLIGHT
RIGHT OUTER TAILLIGHT
SIDE DESIGN MARKER LIGHT LIGHT
SIDE MARKER LIGHT
TAILLIGHT
W/O LED
W/O LED W/ LED
WHT/BLK WIRE
WHT/GRN WIRE
YEL/VIO WIRE
Go to component: -> Exterior lamps & trailer connector circuit (2 of 4) -> AUXILIARY BRAKE LIGHT
