BMW 6 series F06/F13/F12 (2011-2015) 1 3 2 pass seat backrest pass seat backrest sig temp sens Wiring diagram
This page shows the only wiring diagram for the component.1 3 2 pass seat backrest pass seat backrest sig temp sens, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 3 2 pass seat backrest pass seat backrest sig temp sens (1 of 1)
1 2 3 4 VOLT SPLY GND BUS SIG BUS SIG
1 3 2 DR SEAT BACKREST DR SEAT BACKREST SIG TEMP SENS
1 3 2 PASS SEAT BACKREST PASS SEAT BACKREST SIG TEMP SENS
4 3 1 DR SEAT CUSHION SIG TEMP SENS DR SEAT CUSHION
4 3 1 PASS SEAT CUSHION SIG TEMP SENS PASS SEAT CUSHION
5 6 7 BUS SIG BUS SIG PWR SPLY
7 6 5 PWR SPLY BUS SIG BUS SIG
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BACKREST HEATING ELEMENT (IN DRIVER'S SEAT BACK)
DRIVER'S SEAT CUSHION HEATING ELEMENT (IN DRIVER'S SEAT CUSHION)
ELECTRONICS JUNCTION BOX
FUSE
FUSE FUSE (UNDER RIGHT SIDE OF DASH)
GRN WIRE
HEATING/AIR CONDITIONING SYSTEM (CENTER OF DASH)
HOT W/ BISTABLE RELAY ENERGIZED
JUNCTION BOX
NCA WIRE
ORG/GRN WIRE
PASSENGER'S SEAT BACKREST HEATING ELEMENT (IN FRONT PASSENGER'S SEAT BACK)
PASSENGER'S SEAT CUSHION HEATING ELEMENT (IN FRONT PASSENGER'S SEAT CUSHION)
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
W/ 2-CIRCUIT SEAT HEATING
W/ LUMBAR SUPPORT
W/O LUMBAR SUPPORT
Go to component: -> Front heated seats circuit -> 1 3 2 PASS SEAT BACKREST PASS SEAT BACKREST SIG TEMP SENS
