BMW 6 series F06/F13/F12 (2011-2015) 1 2 most data bus circuit Wiring diagram

This page shows the only wiring diagram for the component.1 2 most data bus circuit, which is found in the car BMW 6 series F06/F13/F12 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 1 2 most data bus circuit (1 of 1)

Wiring diagram 1 2 most data bus circuit for BMW 6 series F06/F13/F12 (2011-2015)

Get access

1 2 MOST DATA BUS CIRCUIT AERIAL DIVERSITY BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM NAVIGATION SYSTEM DVD CHANGER ELECTRONIC NIGHT VISION MODULE (UNDER LEFT SIDE OF DASH) FUSE 125 FUSE 121 GRN WIRE GRY WIRE HEAD UNIT (HIGH) HOT W/ TERMINAL NAVIGATION SYSTEM NCA WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM REAR FUSE HOLDER (IN REAR POWER DISTRIBUTION BOX) REAR SEAT ENTERTAINMENT RED WIRE RED/GRN WIRE RED/VIO WIRE VIDEO SWITCH (IF EQUIPPED) W/ OMNIDIRECTIONAL CAMERA, NIGHT VISION CAMERA W/ OMNIDIRECTIONAL CAMERA, W/O NIGHT VISION CAMERA W/ VIDEO SWITCH W/O OMNIDIRECTIONAL CAMERA W/O VIDEO SWITCH W/O VIDEO W/ VIDEO SWITCH SWITCH WHT WIRE YEL WIRE

Go to component: -> Video system circuit -> 1 2 MOST DATA BUS CIRCUIT
