BMW 6 series E63/E64 facelift (2007-2010) trunk lid central locking drive w/ trunk lid contact switch Wiring diagram
This page shows the only wiring diagram for the component.trunk lid central locking drive w/ trunk lid contact switch, which is found in the car BMW 6 series E63/E64 facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk lid central locking drive w/ trunk lid contact switch (1 of 1)
BASIC BODY MODULE (BEHIND GLOVE BOX)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COUPE
EXCEPT COUPE
FLASHLIGHT CHARGING SOCKET
FRONT FUSE HOLDER (BEHIND GLOVE BOX) FUSE 27
FRONT INTERIOR LIGHT
FUSE 11
FUSE 22 FUSE 24
GLOVE COMPARTMENT LIGHT
GLOVE COMPARTMENT LIGHT SWITCH
GRY WIRE
HOT AT ALL TIMES
INTERIOR LIGHTS
LEFT FRONT ENTRANCE LIGHT
LEFT FRONT FOOTWELL LIGHT
LEFT FRONT MAKE UP MIRROR SWITCH
LEFT FRONT MAKE- UP MIRROR LIGHT
LUGGAGE COMPARTMENT LIGHT
MAP READING LIGHTS
NOISE SUPPRESSOR FILTER
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT ENTRANCE LIGHT
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT MAKE UP MIRROR SWITCH
RIGHT FRONT MAKE- UP MIRROR LIGHT
TOP LIGHT
TRUNK LID CENTRAL LOCKING DRIVE W/ TRUNK LID CONTACT SWITCH
VIO WIRE
W/ LIGHT PACKAGE
WHT/BRN WIRE
YEL WIRE
Go to component: -> Courtesy lamps circuit -> TRUNK LID CENTRAL LOCKING DRIVE W/ TRUNK LID CONTACT SWITCH
