BMW 6 series E63/E64 facelift (2007-2010) convertible top compt floor switch Wiring diagram
This page shows the only wiring diagram for the component.convertible top compt floor switch, which is found in the car BMW 6 series E63/E64 facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible top compt floor switch (1 of 1)
BRN WIRE
BRN/RED WIRE
CENTER CONSOLE SWITCH CENTER
COMFORT ACCESS CONTROL MODULE
CONVERTIBLE COUPE 8 6
CONVERTIBLE TOP COMPT FLOOR SWITCH
ELCETROCHROMIC INTERIOR REAR VIEW MIRROR
FUEL TANK ELECTRIC FUEL PUMP
GEAR INDICATOR LIGHTING
HEATING/ AIR CONDITIONING SYSTEM
IVM INTEGRATED SUPPLY MODULE
LIGHT REPEATER
LOWERING REAR WINDOW RELAY
LUGGAGE COMPT SOCKET OUTLET
PASSENGER'S DOOR MICROWAVE SENSOR
PASSENGER'S SEAT ADJUSTMENT SWITCH
PASSENGER'S SEAT MODULE
RAISING REAR WINDOW RELAY
RIGHT FRONT DIRECTION INDICATOR
RIGHT OUTER TAILLIGHT
SECONDARY AIR PUMP RELAY
STEPTRONIC SWITCH
TRUNK LID/ TAILGATE LOCK
Go to component: -> Ground distribution circuit (2 of 7) -> CONVERTIBLE TOP COMPT FLOOR SWITCH
