BMW 6 series E63/E64 facelift (2007-2010) computer data lines system anti-lock brakes system Wiring diagram

ACCELERATOR PEDAL MODULE (AT ACCELERATOR PEDAL) ANTI-THEFT SYSTEM BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE LIGHT SWITCH (LEFT SIDE OF DASH) BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE CLUTCH SWITCH MODULE (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM ANTI-LOCK BRAKES SYSTEM DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE (RIGHT REAR ENGINE COMPT) ELECTRIC THROTTLE VALVE (FRONT OF ENGINE) FAR RANGE SENSOR FUSE FUSE (6 SERIES: IN LUGGAGE COMPT) (5 SERIES: RIGHT SIDE OF REAR COMPT) HOT W/ DME RELAY 1 ENERGIZED INTEGRATED SUPPLY MODULE (IVM) (RIGHT REAR OF ENGINE COMPT) LEFT CLOSE RANGE SENSOR (RIGHT FRONT FLOOR) LONGITUDINAL DYNAMICS MANAGEMENT REAR FUSE HOLDER RED WIRE RED/BLK WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT CLOSE RANGE SENSOR VIO WIRE VIO/BLK WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL/BLU WIRE YEL/GRN WIRE
