Seat ventilation circuit for BMW 6 series Gran Coupe F06 (2011-2015)

Seat ventilation circuit (1 of 2)

6 series Gran Coupe BMW F06 (2011-2015): Seat ventilation circuit (1 of 2)

Get access

1 2 3 4 PWR SPLY GND BUS SIG BUS SIG 1 2 SEAT GND FAN BACK GND FAN 5 6 7 BUS SIG BUS SIG PWR SPLY BACK ACT FAN BLK WIRE BLK/WHT WIRE BRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT BACKREST FAN 1 DRIVER'S SEAT BACKREST FAN 2 DRIVER'S SEAT CUSHION FAN 1 DRIVER'S SEAT CUSHION FAN 2 DRIVER'S SEAT CUSHION FAN 3 DRIVER'S SEAT CUSHION FAN 4 DRIVER'S SEAT DRIVER'S SEAT BACKREST FAN 4 BACKREST FAN 3 ELECTRONICS JUNCTION BOX FUSE FUSE FUSE (UNDER RIGHT SIDE OF DASH) GRN WIRE HEATING/ AIR CONDITIONING SYSTEM (CENTER OF DASH) HOT W/ BISTABLE RELAY ENERGIZED JUNCTION BOX ORG/GRN WIRE RED WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RELAY ENERGIZED SEAT ACT FAN VOLT SPLY W/O LUMBAR SUPPORT W/ LUMBAR SUPPORT WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE

Seat ventilation circuit (2 of 2)

6 series Gran Coupe BMW F06 (2011-2015): Seat ventilation circuit (2 of 2)

Get access

1 2 SEAT GND FAN BACK GND FAN 5 6 7 BUS SIG BUS SIG PWR SPLY BACK ACT FAN BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM GRN WIRE ORG/GRN WIRE PASSENGER'S SEAT BACKREST FAN 1 PASSENGER'S SEAT BACKREST FAN 2 PASSENGER'S SEAT BACKREST FAN 3 PASSENGER'S SEAT BACKREST FAN 4 PASSENGER'S SEAT CUSHION FAN 1 PASSENGER'S SEAT CUSHION FAN 2 PASSENGER'S SEAT CUSHION FAN 3 PASSENGER'S SEAT CUSHION FAN 4 RED WIRE RED/BLU WIRE SEAT ACT FAN VOLT SPLY W/O LUMBAR SUPPORT W/ LUMBAR SUPPORT WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE
