Front lumbar circuit, without active seats for BMW 6 series Gran Coupe F06 (2011-2015)
Front lumbar circuit, without active seats
BRN WIRE
BRN/ORG WIRE
DRIVER'S LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT LUMBAR SUPPORT DRIVE (UNDER DRIVER'S SEAT)
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER
PASSENGER'S LUMBAR SUPPORT VALVE BLOCK (TOP OF FRONT PASSENGER'S SEAT BACK)
PASSENGER'S SEAT LUMBAR SUPPORT DRIVE (UNDER FRONT PASSENGER'S SEAT)
PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER
RED WIRE
RED/BLK WIRE
RELAY ENERGIZED JUNCTION BOX FUSE (UNDER RIGHT SIDE OF DASH)
WHT/YEL WIRE
