Electronic night vision circuit for BMW 6 series Gran Coupe F06 (2011-2015)
Electronic night vision circuit
BASIC, W/ VIDEO SWITCH
BASIC, W/O VIDEO SWITCH
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC NIGHT VISION MODULE (UNDER LEFT SIDE OF DASH)
FUSE 124 (IN REAR POWER DISTRIBUTION BOX)
GRN WIRE
GRN/RED WIRE
GRY WIRE
HEAD UNIT
HIGH W/ VIDEO SWITCH
NCA WIRE
NIGHT VISION CAMERA (BEHIND LEFT FRONT GRILLE)
ORG/ WIRE
REAR FUSE HOLDER
RED WIRE
RELAY ENERGIZED
VIDEO SWITCH
WHT WIRE
YEL/WHT WIRE
