Anti-theft & central locking circuit, convertible for BMW 6 series Gran Coupe F06 (2011-2015)

BLK WIRE BLK/BLU WIRE BLK/BLU/YEL WIRE BLK/BRN WIRE BLK/RED WIRE BLU/BLK WIRE BLU/WHT WIRE BONNET CONTACT SWITCH BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/YEL WIRE CAR ACCESS SYSTEM (UNDER CENTER OF REAR SHELF) CENTRAL LOCKING ACTUATOR STORAGE COMPARTMENT CENTER CONSOLE CENTRAL LOCKING BUTTON HAZARD WARNING SWITCH OPERATING FACILITY COMPUTER DATA LINES SYSTEM DRIVER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE DRIVER'S DOOR SYSTEM LOCK (REAR OF DRIVER'S DOOR) ELECTRONICS JUNCTION BOX JUNCTION BOX (UNDER RIGHT SIDE OF DASH) FOOTWELL MODULE (LEFT END OF DASH) FUSE 14 FUSE 15 FUSE 58 GRN/BLK WIRE GRN/RED WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE HOT AT ALL TIMES HOTEL POSITION SWITCH INTERIOR REAR LID BUTTON LEFT "C" PILLAR) NCA WIRE ORG/ WIRE REAR LID CENTRAL ARREST BUTTON RED WIRE RED/YEL WIRE VIO WIRE VIO/BLU WIRE VIO/GRN WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED/YEL WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE YEL/WHT WIRE

ANTI- THEFT ALARM LED BLK/BRN WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM ELECTROCHROMIC INTERIOR REAR VIEW MIRROR ENERGIZED REAR FUSE CARRIER (IN REAR POWER EXTERIOR BOOT LID BUTTON FRONT PASSENGER'S DOOR SYSTEM LOCK (REAR OF FRONT PASSENGER'S DOOR) FUSE 110 FUSE 144 FUSE 152 DISTRIBUTION BOX) FUSE 169 GRN WIRE GRY/BLK/YEL WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ TERMINAL INTERFERENCE SUPPRESSOR FILTER 2 LEFT "C" PILLAR) LEFT FRONT MICROWAVE SENSOR (IN LEFT FRONT DOOR) LEFT REAR MICROWAVE SENSOR (LEFT SIDE OF LEFT "B" PILLAR) NCA WIRE ORG/ WIRE PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE POWER DISTRIBUTION SYSTEM RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT MICROWAVE SENSOR (IN RIGHT FRONT DOOR) RIGHT REAR MICROWAVE SENSOR (RIGHT SIDE OF RIGHT "B" PILLAR) TERMINATING RESISTOR (RIGHT SIDE OF LUGGAGE COMPT) TRUNK LID ACTUATION W/ REVERSE CAMERA (IF EQUIPPED) W/ REVERSE CAMERA W/O REVERSE CAMERA WHT/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE YEL/WHT WIRE
