Navigation circuit, high level for BMW 5 series G60 (2023-2024)

ANTENNA SIGNAL AMPLIFIER 2 BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM GNSS ANTENNA GRN WIRE GRN/BLU WIRE GRY/GRN WIRE HEAD UNIT (RIGHT KICK PANEL) MOBILE RADIO ANTENNA MOBILE RADIO ANTENNA 2 NCA WIRE REAR MICROPHONE REAR MICROPHONE 2 REAR WINDOW HEATING WAVE TRAP RECEIVER AUDIO MODULE RED/VIO WIRE RED/YEL WIRE ROOF ANTENNA WHT WIRE YEL WIRE

AUGMENTED REALITY CAMERA BASIC CENTRAL PLATFORM (BCP) BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CRASH SAFETY MODULE (ACSM) DAB L ANTENNA FUSE 1 FUSE 67 GNSS ANTENNA GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRY WIRE GRY/GRN WIRE GRY/RED WIRE HOT W/ HOT W/ BI-STABLE RELAY ENERGIZED MOBILE RADIO ANTENNA MOBILE RADIO ANTENNA 2 NCA WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX TELEMATIC COMMUNICATION BOX (CENTER REAR OF ROOF) W/ PERSONAL ESIM W/ TELEMATICS W/O PERSONAL ESIM W/O TELEMATICS WHT WIRE WHT/BLU WIRE WHT/GRY WIRE WHT/RED WIRE YEL/GRY WIRE

BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM CONTROLLER (IDRIVE) DISPLAY GROUP DRIVER CAMERA SYSTEM DRIVER DISPLAY EMERGENCY CALL BUTTON EMERGENCY CALL BUTTON FUNCTION INDICATOR LIGHT EMERGENCY LOUDSPEAKER FUSE 132 GRN WIRE GRN/BLU WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT PANEL LEFT FRONT POWER DISTRIBUTION BOX NAVIGATION SYSTEM NCA WIRE ORG/ WIRE RED/BRN WIRE RED/GRY WIRE RED/YEL WIRE ROOF FUNCTION CENTER WHT WIRE WHT/BLU WIRE WLAN ANTENNA 2 YEL/BRN WIRE YEL/RED WIRE

BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT SMARTPHONE TRAY MODULE (SAMV) FUSE 171 FUSE 38 FUSE 58 FUSE 68 GRN WIRE GRY/GRN WIRE GRY/RED WIRE HEAD UNIT (RIGHT KICK PANEL) HOT AT ALL TIMES HOT W/ LEFT FRONT POWER DISTRIBUTION BOX NCA WIRE NFC NEAR- FIELD COMMUNICATION ORG/ WIRE RED WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT BASS SPEAKER RIGHT FRONT POWER DISTRIBUTION BOX USB CONNECTION WHT WIRE WLAN ANTENNA

ACOUSTIC PEDESTRIAN PROTECTION SPEAKER ACOUSTIC PEDESTRIAN PROTECTION SPEAKER 2 BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FUSE 257 FUSE 262 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ LEFT FRONT BASS SPEAKER LEFT FRONT DOOR BASS SPEAKER LEFT REAR MID- RANGE SPEAKER 2 LEFT REAR TWEETER 2 MICROPHONE NCA WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT DOOR BASS SPEAKER RIGHT REAR MID- RANGE SPEAKER 2 RIGHT REAR TWEETER 2 WHT WIRE YEL WIRE YEL/BLU WIRE

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE FRONT CENTER MID-RANGE SPEAKER FRONT CENTER TWEETER FUSE 258 GRN WIRE GRY WIRE HOT W/ LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER MICROPHONE 2 + NCA WIRE REAR POWER DISTRIBUTION BOX RECEIVER AUDIO MODULE RED/BLU WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TWEETER W/ TELEMATICS W/O TELEMATICS WHT WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE
