BMW 5 series G60 (2023-2024) light source 17 light source 16 Wiring diagrams

BLU WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE CENTER CONSOLE LIGHTING DRIVER SEAT BACKREST LIGHTING DRIVER'S DOOR DRIVER'S DOOR INTERIOR LIGHTING LIN SLAVE DRIVER'S DOOR POCKET LIGHTING DRIVER'S DOOR TOUCH CONTROL BOX DRIVER'S DOOR TWEETER LIGHTING DRIVER'S DOOR WOOFER LIGHTING GRN WIRE GRY WIRE GRY/BLU WIRE GRY/VIO WIRE LIGHT SOURCE 10 LIGHT SOURCE 9 LIGHT SOURCE 11 LIGHT SOURCE 10 LIGHT SOURCE 12 LIGHT SOURCE 11 LIGHT SOURCE 14 LIGHT SOURCE 13 LIGHT SOURCE 15 LIGHT SOURCE 14 LIGHT SOURCE 16 LIGHT SOURCE 15 LIGHT SOURCE 17 LIGHT SOURCE 16 LIGHT SOURCE 18 REAR DRIVER'S SIDE DOOR MID-RANGE SPEAKER LIGHTING REAR DRIVER'S SIDE DOOR SPEAKER LIGHTING REAR DRIVER'S SIDE FOOTWELL LIGHT REAR DRIVER'S SIDE FOOTWELL POCKET LIGHTING RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/WHT WIRE VIO WIRE W/ HIGH END AUDIO YEL/BLK WIRE

BLU/WHT WIRE BOOSTER DRIVER'S DOOR DRIVER'S DOOR INTERIOR LIGHTING LIN SLAVE DRIVER'S DOOR TOUCH CONTROL BOX DRIVER'S SEAT BACKREST LIGHTING GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HIGH-VOLTAGE BATTERY UNIT LIGHT SOURCE 14 LIGHT SOURCE 13 LIGHT SOURCE 15 LIGHT SOURCE 14 LIGHT SOURCE 16 LIGHT SOURCE 15 LIGHT SOURCE 17 LIGHT SOURCE 16 LIGHT SOURCE 18 PNK WIRE REAR DRIVER'S SIDE DOOR MID-RANGE SPEAKER LIGHTING REAR DRIVER'S SIDE DOOR POCKET LIGHTING REAR DRIVER'S SIDE DOOR SPEAKER LIGHTING REAR DRIVER'S SIDE FOOTWELL LIGHT TELEMATIC COMMUNICATION BOX (TCB) (CENTER REAR OF ROOF) VIO WIRE VIO/BLK WIRE W/ HIGH END AUDIO W/ PERSONAL ESIM W/O PERSONAL ESIM WHT WIRE WHT/BLU WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE
