BMW 5 series G60 (2023-2024) driver's door locking function Wiring diagram
This page shows the only wiring diagram for the component.driver's door locking function, which is found in the car BMW 5 series G60 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's door locking function (1 of 1)
BI-STABLE RELAY
BLOWER MOTOR
BLU/GRN WIRE
BRN WIRE
CENTRAL BACKUP FUNCTION
COMBINED CHARGING UNIT (CCU)
DIAGNOSTIC SOCKET
DISPLAY GROUP
DRIVER TOUCH CONTROL BOX
DRIVER'S DOOR LOCKING FUNCTION
DUAL REMOTE CONTROL RECEIVER
FUSE 1
FUSE 2
FUSE 3
FUSE 30
FUSE 31
FUSE 32
FUSE 33
FUSE 34
FUSE 35
FUSE 36
FUSE 37
FUSE 38
FUSE 39
FUSE 4
FUSE 42
FUSE 5
FUSE 6
GEAR SELECTOR SWITCH (GWS)
HEAD UNIT HIGH (HU-H)
HIGH-VOLTAGE BATTERY UNIT
INSTRUMENT CLUSTER (KOMBI)
INSTRUMENT PANEL TOUCH CONTROL BOX
LEFT FRONT REMOTE CONTROL RECEIVER
LOCK FUNCTION
PASSENGER DOOR CONTROL UNIT (TSGBF)
PASSENGER OUTSIDE DOOR HANDLE ELECTRONICS
RAIN/LIGHT/ SOLAR CONDENSATION SENSOR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT REMOTE CONTROL RECEIVER
ROOF FUNCTION CENTER (FZD)
START-STOP BUTTON
STEERING COLUMN SWITCH CLUSTER
TAILGATE FUNCTION MODULE (HKFM)
TELEMATIC COMMUNICATION BOX (TCB)
TO 48 VOLT BATTERY (DIAGRAM 10 OF 10)
UNLOCK FUNCTION
VERTICAL DYNAMICS PLATFORM (VDP)
VIO WIRE
WHT/YEL WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (2 of 10) -> DRIVER'S DOOR LOCKING FUNCTION
