BMW 5 series G30/G31 (2016-2020) heating acc sensor Wiring diagram
This page shows the only wiring diagram for the component.heating acc sensor, which is found in the car BMW 5 series G30/G31 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heating acc sensor (1 of 1)
ACTIVE CRUISE CONTROL
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY DOMAIN CONTROLLER
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
GEAR SELECTOR SWITCH
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
HEATING ACC SENSOR
LEFT MULTI-FUNCTION STEERING COLUMN SWITCH CLUSTER
NCA WIRE
OPTIONAL EQUIPMENT SYSTEM
PMW-BFI
PNK/BLU WIRE
RED WIRE
RIGHT MULTI-FUNCTION STEERING WHEEL SWITCH CLUSTER
SEATS SYSTEM
STEERING COLUMN SWITCH CLUSTER
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Cruise control circuit (2 of 2) -> HEATING ACC SENSOR
