BMW 5 series F10/F11 facelift (2013-2017) charging interface module Wiring diagram
This page shows the only wiring diagram for the component.charging interface module, which is found in the car BMW 5 series F10/F11 facelift (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram charging interface module (1 of 1)
2.0L TURBO
3.0L TURBO
3.0L TURBO DIESEL
4.4L TURBO EXCEPT GT
4.4L TURBO GT, 3.0L TURBO
A/T
ACTIVE CRUISE CONTROL
AUXILIARY BATTERY CHARGING CONTROLLER
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CHARGING INTERFACE MODULE
DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE
DIGITAL MOTOR ELECTRONICS 2
DOUBLE CLUTCH TRANSMISSION
ELECTRONIC MACHINE ELECTRONICS
ELECTRONIC TRANSMISSION CONTROL
EXCEPT GT 4.4L
EXCEPT M5 4.4L TURBO
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/GRN WIRE
GRY/WHT WIRE
GT 4.4L, 3.0L
INTEGRATED CHASSIS MANAGEMENT
INTELLIGENT BATTERY SENSOR
M5 4.4L TURBO, 2.0L TURBO
NCA WIRE
PNK WIRE
PNK/RED WIRE
PNK/WHT WIRE
PRESSURIZED FULL TANK CONTROL MODULE
RADIATOR SHUTTER DRIVE UNIT
RED WIRE
RED/GRN WIRE
RIGHT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
STARTER/ALTERNATOR ELECTRONICS
TERMINATING RESISTOR
TERMINATING RESISTOR 2
TRANSFER BOX
W/O TWIN CLUTCH GEARBOX W/ TWIN CLUTCH GEARBOX
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Computer data lines circuit (6 of 6) -> CHARGING INTERFACE MODULE
