BMW 5 series F10/F11 (2009-2013) w/ high variant roof function module Wiring diagram

BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BOOT LID LIFT BRN WIRE BRN/BLK WIRE BRN/YEL WIRE CAR ACCESS SYSTEM COMBOX (SEDAN) CONTROLLER DIAGNOSIS SOCKET DIAGNOSIS SOCKET TERMINATING RESISTOR DRIVER'S SEAT MODULE (UNDER RIGHT SIDE OF SEAT) ELECTRONIC RIDE HEIGHT CONTROL FOOTWELL MODULE FUSE 3 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/VIO WIRE HOT W/ BI-STABLE RELAY ENERGIZED JUNCTION BOX (RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS ORG/ WIRE ORG/GRN WIRE PASSENGER'S SEAT MODULE (UNDER PASSENGER'S SEAT) PNK 4 5 6 7 8 9 WIRE PNK WIRE PNK/WHT WIRE RAIN/DRIVING LIGHTS/ CONDENSATION /SOLAR SENSOR REAR COMPARTMENT AIR CONDITIONING SYSTEM REAR COMPARTMENT AUTOMATIC CLIMATE CONTROL REAR COMPARTMENT CONTROLLER REAR COMPARTMENT DISPLAY REAR COMPARTMENT DISPLAY 2 REAR DRIVER'S SIDE DOOR SEAT SWITCH CLUSTER REAR DRIVER'S SIDE POWER WINDOW SWITCH REAR DRIVER'S SIDE SEAT MODULE REAR PASSENGER'S SIDE SEAT MODULE RED WIRE RED/BLU WIRE SEDAN TIRE PRESSURE CONTROL (UNDER SPARE TIRE) TRAILER MODULE (UNDER SPARE TIRE) VIO WIRE W/ HIGH VARIANT ROOF FUNCTION MODULE WHT WIRE WHT/BRN WIRE WHT/BRN/YEL WIRE WIPER MODULE YEL WIRE YEL/BRN WIRE YEL/RED WIRE
