BMW 5 series F10/F11 (2009-2013) steering wheel heater, steering column adjuster switch Wiring diagram

This page shows the only wiring diagram for the component.steering wheel heater, steering column adjuster switch, which is found in the car BMW 5 series F10/F11 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram steering wheel heater, steering column adjuster switch (1 of 1)

Wiring diagram steering wheel heater, steering column adjuster switch for BMW 5 series F10/F11 (2009-2013)

Get access

1 2 M+ M- 1 4 2 3 LHZ+ LHZ- T_LHZ+ T_LHZ- 11 9 GND SPLY AUSW BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/VIO WIRE ELECTRONIC STEERING WHEEL MODULE (PART OF STEERING WHEEL) FUSE 24 BOX (RIGHT SIDE OF DASH) GND BWMBFI RAENDEL GRN/BLU WIRE HORN BUTTON JUNCTION JUNCTION BOX ELECTRONICS LEFT STEERING WHEEL MULTI-FUNCTION SWITCH BLOCK NCA WIRE ORG/GRN WIRE RED WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT STEERING WHEEL MULTI-FUNCTION SWITCH BLOCK STEERING COLUMN SWITCH CLUSTER STEERING WHEEL HEATER STEERING WHEEL HEATER, STEERING COLUMN ADJUSTER SWITCH VIBRATION ACTIVATOR VIO WIRE YEL WIRE

Go to component: -> Heated steering wheel circuit -> STEERING WHEEL HEATER, STEERING COLUMN ADJUSTER SWITCH
