BMW 5 series F10/F11 (2009-2013) rear passenger's side lumbar support valve block Wiring diagrams

This page contains all the electrical diagrams for the component. rear passenger's side lumbar support valve block, in which he is found in the car BMW 5 series F10/F11 (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rear passenger's side lumbar support valve block (1 of 2)

Wiring diagram rear passenger's side lumbar support valve block for BMW 5 series F10/F11 (2009-2013)

Get access

4 3 9 8 2 7 1 5 11 10 6 12 LUM SUP VOLT LUM SUP GND 4 5 6 7 8 BUS SIG BUS SIG BUS SIG PWR SPLY GND BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE BUS SIG BUS SIG BUS SIG BUS SIG PWR SPLY GND COMPUTER DATA LINES SYSTEM FUSE FUSE FUSE GRN WIRE GRY/WHT WIRE GRY/YEL WIRE LUGGAGE COMPARTMENT SEAT ADJUSTMENT SWITCH CLUSTER ORG/GRN WIRE PWR SPLY REAR DRIVER'S SIDE DOOR SEAT SWITCH CLUSTER REAR DRIVER'S SIDE LUMBAR SUPPORT VALVE BLOCK REAR DRIVER'S SIDE MASSAGE SEAT PRESSURE DISTRIBUTOR REAR DRIVER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER REAR DRIVER'S SIDE SEAT MODULE REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) REAR PASSENGER'S SIDE DOOR SEAT SWITCH CLUSTER REAR PASSENGER'S SIDE LUMBAR MASSAGE SEAT DRIVE REAR PASSENGER'S SIDE LUMBAR SUPPORT VALVE BLOCK REAR PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER REAR PASSENGER'S SIDE SEAT MODULE RED/BLK WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED VALVE 1 VALVE 2 VALVE 3 VALVE 4 W/ LONG VERSION WHT/BLU WIRE WHT/YEL WIRE YEL/GRY WIRE YEL/RED WIRE

Go to component: -> Rear lumbar circuit, with massage -> REAR PASSENGER'S SIDE LUMBAR SUPPORT VALVE BLOCK

Wiring diagram rear passenger's side lumbar support valve block (2 of 2)

Wiring diagram rear passenger's side lumbar support valve block for BMW 5 series F10/F11 (2009-2013)

Get access

4 5 6 7 8 BUS SIG BUS SIG BUS SIG PWR SPLY GND BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/YEL WIRE BUS SIG COMPUTER DATA LINES SYSTEM FUSE FUSE FUSE GRN WIRE GRY/WHT WIRE GRY/YEL WIRE LUGGAGE COMPARTMENT SEAT ADJUSTMENT SWITCH CLUSTER NCA WIRE ORG/GRN WIRE PWR SPLY REAR DRIVER'S SIDE LUMBAR SUPPORT DRIVE REAR DRIVER'S SIDE LUMBAR SUPPORT VALVE BLOCK REAR DRIVER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER REAR DRIVER'S SIDE SEAT MODULE REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) REAR PASSENGER'S SIDE LUMBAR SUPPORT DRIVE REAR PASSENGER'S SIDE LUMBAR SUPPORT VALVE BLOCK REAR PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER REAR PASSENGER'S SIDE SEAT MODULE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED VALVE 1 VALVE 2 VALVE 3 VALVE 4 WHT/BLU WIRE WHT/YEL WIRE

Go to component: -> Rear lumbar circuit, without massage -> REAR PASSENGER'S SIDE LUMBAR SUPPORT VALVE BLOCK
