BMW 5 series F10/F11 (2009-2013) rear driver's side automatic soft-close drive Wiring diagrams

This page contains all the electrical diagrams for the component. rear driver's side automatic soft-close drive, in which he is found in the car BMW 5 series F10/F11 (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rear driver's side automatic soft-close drive (1 of 2)

Wiring diagram rear driver's side automatic soft-close drive for BMW 5 series F10/F11 (2009-2013)

Get access

BLK/BRN WIRE BLK/GRY WIRE BLU/GRY WIRE BRN WIRE ENERGIZED REAR FUSE HOLDER (RIGHT SIDE OF FUSE 110 FUSE 143 FUSE 144 FUSE 149 REAR COMPT) FUSE 169 GRN/YEL WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ TERMINAL NCA WIRE ORG/ WIRE PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE PASSENGER'S DOOR SYSTEM LOCK (REAR OF FRONT PASSENGER'S SEAT) REAR DRIVER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE REAR DRIVER'S SIDE SYSTEM LOCK REAR PASSENGER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE REAR PASSENGER'S SIDE SYSTEM LOCK RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE WHT/BLK WIRE WHT/BRN WIRE YEL/WHT WIRE

Go to component: -> Anti-theft & central locking circuit (2 of 2) -> REAR DRIVER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE

Wiring diagram rear driver's side automatic soft-close drive (2 of 2)

Wiring diagram rear driver's side automatic soft-close drive for BMW 5 series F10/F11 (2009-2013)

Get access

BLK/BRN WIRE BLK/GRY WIRE BLU/GRY WIRE BRN WIRE ENERGIZED REAR FUSE HOLDER (RIGHT SIDE OF FUSE 110 FUSE 143 FUSE 144 FUSE 149 REAR COMPT) FUSE 169 GRN/YEL WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ TERMINAL NCA WIRE ORG/ WIRE PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE PASSENGER'S DOOR SYSTEM LOCK (REAR OF FRONT PASSENGER'S SEAT) REAR DRIVER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE REAR DRIVER'S SIDE SYSTEM LOCK REAR PASSENGER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE REAR PASSENGER'S SIDE SYSTEM LOCK RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE WHT/BLK WIRE WHT/BRN WIRE YEL/WHT WIRE

Go to component: -> Power door locks circuit (2 of 2) -> REAR DRIVER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE
