BMW 5 series F10/F11 (2009-2013) hot w/ load shedding relay energized fuse fuse 01 holder Wiring diagram
This page shows the only wiring diagram for the component.hot w/ load shedding relay energized fuse fuse 01 holder, which is found in the car BMW 5 series F10/F11 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ load shedding relay energized fuse fuse 01 holder (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
CHARACTERISTIC MAP THERMOSTAT (LEFT FRONT OF ENGINE)
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS
ELECTRIC FAN (RIGHT FRONT SIDE OF ENGINE COMPT)
ELECTRIC FAN CUTOFF RELAY
ENERGIZED JUNCTION FUSE 46 BOX (RIGHT SIDE OF DASH)
ENGINE COOLANT TEMPERATURE SENSOR (FRONT OF ENGINE)
FRONT POWER DISTRIBUTION BOX
FUSE 47
FUSE 505
FUSE 59
FUSE BOX (UNDER SPARE
GRN/RED WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ LOAD SHEDDING RELAY ENERGIZED FUSE FUSE 01 HOLDER
HOT W/ TERMINAL
INTERCOOLER COOLANT PUMP
NCA WIRE
ORG (OR RED/GRN) WIRE
ORG/ WIRE
RADIATOR SHUTTER DRIVE UNIT
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED REAR FUSE HOLDER (RIGHT FUSE 137
SIDE OF REAR COMPT)
TIRE)
TURBOCHARGER COOLANT PUMP
VIO WIRE
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component: -> Cooling fan circuit -> HOT W/ LOAD SHEDDING RELAY ENERGIZED FUSE FUSE 01 HOLDER
