BMW 5 series F10/F11 (2009-2013) fuse 60 fuse 40 Wiring diagram
This page shows the only wiring diagram for the component.fuse 60 fuse 40, which is found in the car BMW 5 series F10/F11 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 60 fuse 40 (1 of 1)
32 4 46 41 16 SPLY TERM 30 SPD SIG SW SIG LED IND GND
BLU/BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DYNAMIC STABILITY CONTROL (DSC)
FUSE
FUSE 60 FUSE 40
GRN/RED WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES REAR FUSE HOLDER FUSE (RIGHT SIDE OF REAR COMPT)
JUNCTION BOX (RIGHT SIDE OF DASH)
PARKING BRAKE BUTTON
PARKING BRAKE CONTROL UNIT
RED WIRE
RED/GRY WIRE
RED/YEL WIRE
YEL/VIO WIRE
Go to component -> Shift interlock circuit -> FUSE 60 FUSE 40
