BMW 5 series F10/F11 (2009-2013) dr seat backrest Wiring diagram

1 2 3 4 5 6 7 8 GND 1 2 3 4 VOLT SPLY GND BUS SIG BUS SIG 1 2 3 DR SEAT BACKREST 1 2 3 DR SEAT CUSHION SIG TEMP SENS DR SEAT CUSHION 1 2 3 PASS SEAT BACKREST 1 2 3 PASS SEAT CUSHION SIG TEMP SENS PASS SEAT CUSHION 48 49 BUS SIG BUS SIG 7 8 BUS SIG BUS SIG BLK/VIO WIRE BLK/WHT WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/YEL WIRE BUS SIG BUS SIG GND CENTRAL GATEWAY MODULE COMPUTER DATA LINES SYSTEM DR SEAT BACKREST DRIVER'S SEAT BACKREST HEATING ELEMENT (IN DRIVER'S SEAT BACKREST) DRIVER'S SEAT CUSHION HEATING ELEMENT (IN DRIVER'S SEAT CUSHION) DRIVER'S SEAT HEATING MODULE FUSE GRN WIRE HEATING/AIR CONDITIONING SYSTEM HOT W/ BISTABLE RELAY ENERGIZED JUNCTION BOX (RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS ORG/GRN WIRE PASS SEAT BACKREST PASSENGER'S SEAT BACKREST HEATING ELEMENT (IN FRONT PASSENGER'S SEAT BACKREST) PASSENGER'S SEAT CUSHION HEATING ELEMENT (IN FRONT PASSENGER'S SEAT CUSHION) PASSENGER'S SEAT HEATING MODULE PWR SPLY GND REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) RED/BRN WIRE RED/GRN WIRE RED/WHT WIRE RELAY ENERGIZED YEL WIRE YEL/BRN WIRE YEL/RED WIRE
