BMW 5 series F10/F11 (2009-2013) disa actuator motor 2 Wiring diagram

This page shows the only wiring diagram for the component.disa actuator motor 2, which is found in the car BMW 5 series F10/F11 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram disa actuator motor 2 (1 of 1)

Wiring diagram disa actuator motor 2 for BMW 5 series F10/F11 (2009-2013)

Get access

BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN WIRE CHARCOAL FILTER VALVE CRANKSHAFT SENSOR (LEFT REAR SIDE OF ENGINE) DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE (RIGHT REAR ENGINE COMPT) DISA ACTUATOR MOTOR 1 DISA ACTUATOR MOTOR 2 ELECTRIC THROTTLE VALVE ACTUATOR HOT FILM AIR MASS METER INTAKE PIPE PRESSURE SENSOR (TOP OF ENGINE) NCA WIRE OIL CONDITION SENSOR (RIGHT REAR OF ENGINE) ORG/ WIRE RED/GRN WIRE STARTING/CHARGING SYSTEM VIO WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component: -> Wiring diagram engine performance 3.0l (1 of 5) -> DISA ACTUATOR MOTOR 2
