BMW 5 series F10/F11 (2009-2013) diagnosis socket Wiring diagrams
This page contains all the electrical diagrams for the component. diagnosis socket, in which he is found in the car BMW 5 series F10/F11 (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram diagnosis socket (1 of 7)
Go to component -> Computer data lines circuit (2 of 3) -> DIAGNOSIS SOCKET
Wiring diagram diagnosis socket (2 of 7)
Go to component -> Ground distribution circuit (1 of 6) -> DIAGNOSIS SOCKET
Wiring diagram diagnosis socket (3 of 7)
Go to component -> Ground distribution circuit (4 of 6) -> DIAGNOSIS SOCKET
Wiring diagram diagnosis socket (4 of 7)
Go to component -> Power distribution circuit (1 of 6) -> DIAGNOSIS SOCKET
Wiring diagram diagnosis socket (5 of 7)
Go to component -> Power distribution circuit (1 of 7) -> DIAGNOSIS SOCKET
Wiring diagram diagnosis socket (6 of 7)
Go to component -> Wiring diagram engine performance 3.0l twin turbo (5 of 5) -> DIAGNOSIS SOCKET
Wiring diagram diagnosis socket (7 of 7)
Go to component -> Wiring diagram engine performance 4.4l twin turbo (1 of 6) -> DIAGNOSIS SOCKET
