BMW 5 series F10/F11 (2009-2013) computer data lines Wiring diagram
This page shows the only wiring diagram for the component.computer data lines, which is found in the car BMW 5 series F10/F11 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram computer data lines (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
CHARACTERISTIC MAP THERMOSTAT (FRONT OF ENGINE)
COMPUTER DATA LINES
DIGITAL MOTOR ELECTRONICS (RIGHT REAR ENGINE COMPT)
ELECTRIC FAN (RIGHT FRONT SIDE OF ENGINE COMPT)
END LOCATOR POSITION LIGHTING SWITCH
ENERGIZED JUNCTION FUSE 47 BOX (RIGHT SIDE OF DASH)
ENGINE COOLANT TEMPERATURE SENSOR (FRONT OF ENGINE)
FUSE 46
FUSE 59
FUSE HOLDER
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ LOAD SHEDDING RELAY ENERGIZED FUSE 01
HOT W/ TERMINAL
INTERCOOLER COOLANT PUMP
LEFT FRONT VENTILATION GRILLE
NCA WIRE
ORG/ WIRE
RADIATOR OUTLET TEMPERATURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
RADIATOR SHUTTER DRIVE UNIT
RADIATOR SHUTTER SOLINOID
RED WIRE
RED/GRN WIRE
SYSTEM
TURBOCHARGER COOLANT PUMP
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component: -> Automatic a/c circuit, with rear automatic climate control (2 of 4) -> COMPUTER DATA LINES
