BMW 5 series F10/F11 (2009-2013) central sensor Wiring diagram
This page shows the only wiring diagram for the component.central sensor, which is found in the car BMW 5 series F10/F11 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram central sensor (1 of 1)
AIR BAG - AIR BAG + AIR BAG - AIR BAG + AIR BAG - AIR BAG +
AIR BAG IND LAMP
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/ORG WIRE
CENTRAL SENSOR
CRASH SAFETY MODULE
GRN WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HIGH VARIANT ROOF FUNCTIONS MODULE
LEFT FRONT PEDESTRIAN GUARD ACTUATOR
LEFT REAR PEDESTRIAN GUARD ACTUATOR
NCA WIRE
OCCUPANCY DETECTION
ORG/GRN WIRE
PASSENGER'S SEAT BELT BUCKLE CONTACT
RED/YEL WIRE
RIGHT "B" PILLAR AIR BAG SENSOR (BOTTOM OF RIGHT "B" PILLAR)
RIGHT CENTER PEDESTRIAN PEDESTRIAN SENSOR SENSOR
RIGHT FRONT AIR BAG SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER)
RIGHT FRONT DOOR AIR BAG SENSOR (FRONT OF FRONT PASSENGER'S DOOR)
RIGHT FRONT PEDESTRIAN GUARD ACTUATOR
RIGHT FRONT SEAT BELT FORCE LIMITER GENERATOR
RIGHT HEAD AIR BAG INFLATOR ASSEMBLY
RIGHT REAR PEDESTRIAN GUARD ACTUATOR
SIGNAL BUS SIG
TENSIONER - TENSIONER +
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
Go to component: -> Supplemental restraints circuit (2 of 2) -> CENTRAL SENSOR
