BMW 5 series F10/F11 (2009-2013) central gateway Wiring diagram
This page shows the only wiring diagram for the component.central gateway, which is found in the car BMW 5 series F10/F11 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram central gateway (1 of 1)
ANGLE
BACK FRONT
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CENTRAL GATEWAY
COMPUTER DATA LINES SYSTEM
DN UP
FUSE
FUSE 53
FWD/BWD
GRN WIRE
GRY WIRE
HEADREST
HEIGHT
JUNCTION BOX (RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
PASSENGER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE
PASSENGER'S SEAT HEADREST HEIGHT ADJUSTMENT DRIVE
PASSENGER'S SEAT HEIGHT ADJUSTMENT DRIVE (UNDER FRONT PASSENGER'S SEAT)
PASSENGER'S SEAT TILT ADJUSTMENT DRIVE
PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RELAY ENERGIZED
TILT
VIO WIRE
W/ SEMI-ELECTRICAL SEAT ADJUSTMENT
W/O SEMI-ELECTRICAL SEAT ADJUSTMENT
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Passenger power seat circuit -> CENTRAL GATEWAY
