BMW 5 series F10/F11 (2009-2013) car information computer basic w/o video switch Wiring diagram

This page shows the only wiring diagram for the component.car information computer basic w/o video switch, which is found in the car BMW 5 series F10/F11 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram car information computer basic w/o video switch (1 of 1)

Wiring diagram car information computer basic w/o video switch for BMW 5 series F10/F11 (2009-2013)

Get access

BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE CAR INFORMATION COMPUTER BASIC W/ VIDEO SWITCH CAR INFORMATION COMPUTER BASIC W/O VIDEO SWITCH CAR INFORMATION COMPUTER HIGH COMPUTER DATA LINES SYSTEM ELECTRONIC NIGHT VISION MODULE FUSE 124 (RIGHT SIDE OF REAR COMPT) GRN WIRE GRN/RED WIRE GRY WIRE HEAD UNIT NCA WIRE NIGHT VISION CAMERA (LEFT SIDE OF FRONT BUMPER) ORG/ WIRE REAR FUSE HOLDER RED WIRE RELAY ENERGIZED VIDEO SWITCH WHT WIRE YEL/WHT WIRE

Go to component: -> Electronic night vision circuit -> CAR INFORMATION COMPUTER BASIC W/O VIDEO SWITCH
