BMW 5 series F10/F11 (2009-2013) aerial sig aerial sig Wiring diagram
This page shows the only wiring diagram for the component.aerial sig aerial sig, which is found in the car BMW 5 series F10/F11 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram aerial sig aerial sig (1 of 1)
35 26 K-CAN BUS SIG K-CAN BUS SIG
AERIAL SIG AERIAL SIG
BLK WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
BUMPER AERIAL
CAR ACCESS SYSTEM
COMPUTER DATA LINES SYSTEM
CONTACT-FREE TAILGATE OPENING EVALUTION ELECTRONICS
CONTACT-FREE TAILGATE OPENING LOWER SENSOR
CONTACT-FREE TAILGATE OPENING UPPER SENSOR
FUSE 2
HOT W/ BISTABLE RELAY ENERGIZED
JUNCTION BOX (RIGHT SIDE OF DASH)
RED WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Contact-free tailgate opening circuit -> AERIAL SIG AERIAL SIG
