Passenger"s memory seat circuit, with lumbar support, with active seats for BMW 5 series E60/E61 facelift (2007-2010)

BLK WIRE BLK/BRN WIRE BLK/VIO WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM INTERIOR LIGHTS SYSTEM FRONT FUSE HOLDER (UNDER RIGHT SIDE OF DASH) FUSE GRN/BLK WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE HOT AT ALL TIMES PASSENGER'S SEAT ADJUSTMENT SWITCH PASSENGER'S SEAT ANGLE ADJUSTMENT DRIVE (UNDER FRONT PASSENGER'S SEAT) PASSENGER'S SEAT DEPTH ADJUSTMENT DRIVE PASSENGER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE PASSENGER'S SEAT HEIGHT ADJUSTMENT DRIVE (UNDER FRONT PASSENGER'S SEAT) PASSENGER'S SEAT MODULE (UNDER PASSENGER'S SEAT) REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) RED/BRN WIRE RED/GRN WIRE RED/WHT WIRE RELAY ENERGIZED SEATS SYSTEM (HEATED SEAT CIRCUIT) VIO/GRY WIRE VIO/RED WIRE W/ SEMI- ELECTRIC BASIC SEAT W/O SEMI- ELECTRIC BASIC SEAT WHT/BLU WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

BLK/BLU WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE PASSENGER'S SEAT BACKREST HEAD ADJUSTMENT MOTOR (RIGHT SIDE OF SEATBACK) PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT MOTOR (BOTTOM LEFT OF SEATBACK) PASSENGER'S SEAT HEAD RESTRAINT ADJUSTMENT DRIVE PASSENGER'S SEAT MODULE (UNDER PASSENGER'S SEAT) SEATS SYSTEM (ORTHOPEDIC CIRCUIT) SEATS SYSTEM (SEAT VENTILATION CIRCUIT) WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BLU WIRE YEL/RED WIRE
