Cruise control circuit, without lrr for BMW 5 series E60/E61 facelift (2007-2010)
Cruise control circuit, without lrr
ACCELERATOR PEDAL MODULE (AT ACCELERATOR PEDAL)
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH (LEFT SIDE OF DASH)
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
CLUTCH SWITCH MODULE (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE (RIGHT REAR ENGINE COMPT)
ELECTRIC THROTTLE VALVE (FRONT OF ENGINE)
FUSE
FUSE (6 SERIES: IN LUGGAGE COMPT) (5 SERIES: RIGHT SIDE OF REAR COMPT)
HOT W/ DME RELAY 1 ENERGIZED
INTEGRATED SUPPLY MODULE (IVM) (RIGHT REAR OF ENGINE COMPT)
REAR FUSE HOLDER
RED WIRE
RED/BLK WIRE
RELAY ENERGIZED
SAFETY, GATEWAY MODULE
STEERING COLUMN SWITCH CLUSTER
VIO WIRE
VIO/BLK WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
