Anti-theft & central locking circuit for BMW 5 series E60/E61 facelift (2007-2010)

ANTI-THEFT ALARM SYSTEM (SEDAN: BEHIND SUNROOF) (WAGON: REAR CENTER OF ROOF) BLK WIRE BLK/BLU WIRE BLK/YEL WIRE BLU/RED WIRE BLU/YEL WIRE BODY-GATEWAY MODULE (UNDER RIGHT SIDE OF DASH) BRN WIRE BRN/BLK WIRE BRN/YEL WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SYSTEM LOCK (REAR OF DRIVER'S DOOR) ELECTROCHROMIC INTERIOR REAR VIEW MIRROR FRONT FUSE HOLDER (UNDER RIGHT SIDE OF DASH) FUSE GRN WIRE GRY/BLK/YEL WIRE HAZARD WARNING/ CENTRAL LOCKING SWITCH HOOD CONTACT (RIGHT REAR ENGINE COMPT) HOT AT ALL TIMES PASSENGER'S DOOR SYSTEM LOCK (REAR OF FRONT PASSENGER'S DOOR) REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) RED WIRE RED/BLK WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SIREN, TILT ALARM SENSOR (WAGON) (RIGHT REAR WHEELWELL) VIO WIRE VIO/GRN WIRE W/O PANORAMIC ROOF WHT WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE

BASIC BODY MODULE (BEHIND GLOVE BOX) BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLU WIRE BLU/BRN WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE FRONT FUSE HOLDER (UNDER RIGHT SIDE OF DASH) FUSE FUSE FUSE GRN WIRE HOT AT ALL TIMES LEFT REAR AUTOMATIC SOFT-CLOSE DRIVE LEFT REAR DOOR SYSTEM LOCK PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) RED WIRE RED/BLK WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT REAR AUTOMATIC SOFT-CLOSE DRIVE VIO WIRE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE
