BMW 5 series E60/E61 facelift (2007-2010) passenger's active bracket width adjustment Wiring diagram
This page shows the only wiring diagram for the component.passenger's active bracket width adjustment, which is found in the car BMW 5 series E60/E61 facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's active bracket width adjustment (1 of 1)
AUC SENSOR
BRN WIRE
BRN/RED WIRE
COMFORT ACCESS CONTROL MODULE
EXTERIOR TRUNK LID/ BUTTON
FLOOR) REAR COMPARTMENT INTERIOR LIGHT
FRESH AIR TEMPERATURE SENSOR
GEAR INDICATOR LIGHTING
GLOVE BOX CHARGING SOCKET
HEATING/ AIR CONDITIONING SYSTEM
HYDRAULIC PUMP
IVM INTEGRATED SUPPLY MODULE
LEFT LICENSE PLATE LIGHT
NCA WIRE
PASSENGER'S ACTIVE BRACKET WIDTH ADJUSTMENT
PASSENGER'S LUMBAR SUPPORT SWITCH
PASSENGER'S PASSENGER'S SEAT LUMBAR ADJUSTMENT SUPPORT SWITCH VALVE BLOCK
PASSENGER'S SEAT ADJUSTMENT SWITCH
PASSENGER'S SEAT MODULE
RED BRN/ WIRE
RIGHT FRONT
RIGHT FRONT DIRECTION INDICATOR SECONDARY AIR PUMP LIGHT REPEATER RELAY
RIGHT LICENSE PLATE LIGHT
RIGHT OUTER RIGHT TAILLIGHT TAILLIGHT
RIGHT REAR INNER WINDOW TAILLIGHT BUTTON
RIGHT REAR INTERIOR LIGHT
SEDAN
SELECTOR LEVER
SEMI-ELECTRIC BASIC SEAT
SHIFT LOCK SELECTOR LEVER LOCK
SMG TRANSMISSION
STEPTRONIC SWITCH
SUNROOF
TRAILER SOCKET
TRANSMISSION MAIN SHAFT RPM SENSOR
TRUNK LID/TAIL- TRUNK GATE LOCK LID/TAIL- SWITCH GATE LOCK
W/ PANORAMIC ROOF
W/O PANORAMIC ROOF
WAGON
WAGON SEDAN
WINDSHIELD WIPER RELAY
Go to component -> Ground distribution circuit (2 of 7) -> PASSENGER'S ACTIVE BRACKET WIDTH ADJUSTMENT
